AFPK1543 Electric Submersible Wastewater Pumps

AFPK1543 Electric Submersible Wastewater Pumps

Sykes’ AFPK1543 is a robust medium-sized 6” electric submersible wastewater pump suitable for commercial, industrial and utility applications. This particular model comes in either a 14kW or a 16kW version and delivers maximum flows of up to 110 litres per second. Capable of operating on a guide rail or freestanding, the AFPK1543 can operate at heads of 31 metres and features motor temperature sensors to ensure the pump always functions at full capacity.

Key Features

Feature

Feature

[acf_repeater]

Product Specification

Additional information

Motor type	415V (3-Phase) 50Hz
Motor rating	16kW
Running current	32A
Running speed	1450 rpm
Discharge port	150mm
Suction inlet port	150mm
Maximum solids	100mm
EX Rated	Yes/No
Cooling jacket	Yes/No
Guide rail option	1155 x 585mm
Transportable option	1325 x 998mm
Weight	370kg

Downloads

Accessories

22KW SOFT START STARTER
6″ X 3M W/A BAUER HOSE
6″ 20FT W/A SUCTION HOSE BAUER
6″ 20FT POLYTUBE
6″ X 6M HELIFLEX PVC BAUER
6″ X 6MTR STEEL BAUER PIPE
6″ 45* BAUER BEND
6″ 90* BEND
6″ GATEVALVE
6″ NON-RETURN VALVE
ROAD RAMP C/W 6″ PN16 FLANGES
ROAD RAMP WIDE C/W 6″ PN16 FLANGES
ROAD CROSSING C/W 8″ PN16 FLANGES

Environments

Building and construction
Emergency
Municipal treatment sites
Wastewater pumping networks
Sewage
Manufacturing and industry
Industrial processes
Commercial drainage
Food preparation processes
Agriculture
Utility ind
